UL标准电缆的最小厚度是怎么回事
UL标准绝缘跟护套均匀厚度怎样算的,没变跟国标算法有什么不同么
均匀厚度是经过UL标准设定的乘以0.0254吧、那他的最小厚度呢?是用他的均匀厚度乘以0.9减去0.1么?要害就是他的最小厚度让人搞不懂,好像是绝缘层的最小厚度跟护套层的不一样吧?
15mils是均匀厚度 13mils是恣意点的最小厚度 按均匀厚度15mils做线材 但最薄不能小于13mils 不然就是不符合UL标准了
APPLIANCE WIRING MATERIAL |
Subj.758 | Section 1 | Page 1007 | Issued:1959-05-01 |
Revised:2013-02-22 |
Style 1007 | Single Conductor with Extruded Insulation |
Rating | 80 deg C, 300 Vac, Horizontal flame. Optional - 60 deg C or 80 deg C Oil. | |||||||||
Conductor | 32 AWG - 16 AWG, Solid or Stranded. | |||||||||
Insulation | Extruded PVC, 15 mils minimum average thickness, 13 mils minimum thickness at any point. | |||||||||
Standard | Appliance Wiring Material UL 758. | |||||||||
Marking | General. | |||||||||
Use | Internal wiring of appliances. Tags may indicate the following: 600 V Peak - For Electronic Use Only. |
